10YXJ3300M12.5X20
Part number：
10YXJ3300M12.5X20
CLASSIFICATION：
Capacitors
manufacturer：
Rubycon
describe：
CAP ALUM 3300UF 20% 10V RADIAL
package：
Bulk
ROHS status：
Yes
currency：
USD
BUY NOW add to cart
inventory 2027
minimum : 0
quantity
unit price
price
1
1.05
1.05
10
0.67
6.7
50
0.5
25
100
0.45
45
500
0.36
180
1000
0.34
340
3000
0.31
930
5000
0.29
1450
specifications
  • Tolerance
    ±20%
  • Package / Case
    Radial, Can
  • Size / Dimension
    0.492" Dia (12.50mm)
  • Polarization
    Polar
  • Mounting Type
    Through Hole
  • Operating Temperature
    -40°C ~ 105°C
  • Applications
    General Purpose
  • Lead Spacing
    0.197" (5.00mm)
  • Lifetime @ Temp.
    8000 Hrs @ 105°C
  • Height - Seated (Max)
    0.866" (22.00mm)
  • Capacitance
    3300 µF
  • Voltage - Rated
    10 V
  • Impedance
    41 mOhms
  • Ripple Current @ Low Frequency
    1.52 A @ 120 Hz
  • Ripple Current @ High Frequency
    1.9 A @ 100 kHz
